Analog Voltmeter With Pointer

Description

The voltmeter measures in volts the potential difference of an electrical circuit. Tech Specification:- • Accuracy: class 1.5. • Ferromagnetic devices. • Scale length: 80mm over 90*. • Mounting in enclosure or cubicle. • Maximum operating position: 30*/vertical. • Temperature: Operation -25*C to 50*C. • Influence of temperature on accuracy: +-0.003%/*C. • Utilization frequency: 50/60HZ. • Consumption: 3VA. • Permanent overload: 1.2Un. • Maximum overload for 5s:2Un.
